Technical specifications
Specification Typical PA-1000
Maximum rated load 500 kg single hook; 1,000 kg double hook
Power supply 220–230 V, single phase on common versions
Motor power Approximately 1.6–2.0 kW
Lifting speed About 8 m/min single; 4 m/min double
Lifting height Typically 12 m single; 6 m double
Net weight Approximately 30–32 kg
Controls Wired pendant; emergency stop and limit switches
