Circulation pump with 1-phase wet rotor motor, performance adjustment through 3 speed levels, speed levels selectable via step switch, external motor protection not required. Pump and motor form a unit, meaning maintenance-free bearing lubrication through the pumped medium, shaft sealing is therefore not required.
Axial bearings made of carbon
Bearing plate and can made of stainless steel
Housing made of stainless steel
Medium temperature: max. 110°C
Ambient temperature: max. 40°C (at 80°C medium temperature)
Test mark: VDE, GS, CE
Operating pressure: max .10 bar
Pipe connection: G 1 1/2"
Installation length: 180 mm
Power levels switchable: 65W/80W/85W
Energy label: C
el. Connection: 230V/50HZ
Insulation class: F
Weight: 4.5 kg
Scope of delivery: pump , gasket set, operating instructions
