Key Technical Specifications
Print Method: Dye-sublimation / resin thermal transfer.
Resolution: 300 dpi (11.8 dots/mm).
Print Speed:
YMCKO: 16 seconds per card / 225 cards per hour.
YMCKOK: 24 seconds per card.
Monochrome: 6 seconds per card.
Accepted Card Sizes: CR-80 (3.375" L x 2.125" W) and CR-79 Adhesive Back (3.313" L x 2.063" W).
Card Capacity: Dual-input hopper holds 200 cards; Output hopper holds 100 cards.
Print Area: Edge-to-edge (CR-80).
Accepted Card Thickness: Print only: .009" - .040" / 9 mil - 40 mil.
Interface: USB 2.0 and Ethernet with internal print server.
Security & Features
Security Features: AES-256 data encryption, optional locking card hoppers, and holographic image lamination.
Encoding Options: Field-upgradable options for magnetic stripe, proximity, and contactless smart cards
