Applications
Single impeller centrifugal pumps suitable to cover any small, medium or large capacity request; for domestic, agricultural and industrial purposes; with automatic water distribution ; for sprinkler and flood irrigation systems in gardening and agriculture; to increase in derivation system pressure in aqueducts.
Operating Conditions
Liquid temperature up to 86°F (for home use according to EN 60335-2-41)
Temperature max. liquid: 140°F (for other uses)Ambient temperature up to 104°F
Total suction lift up to 23ft.
Motor
Two-Pole induction motor (n = 3450 min-1)
Insulation Class F
Protection IP 44
Materials
Pump body: Cast Iron
Motor Support: Cast Iron
Impeller: Stainless Steel AISI 304
Shaft with rotor: Stainless Steel AISI 304
Mechanical seal: CeramicSperoni CM 32
0.75kw, 230v
Flow: 10 to 125 L/Min
Head: 10 to 29mts
