• Pump Body & Support: Heavy-duty cast iron featuring a specialized anti-rust treatment to protect against internal corrosion.
• Impeller: Engineered with a brass impeller paired with an anti-block system to stop the component from locking up or seizing after sitting idle.
• Motor Windings: Features a high-conductivity copper winding motor.
• Shaft Material: Built with durable AISI 304 stainless steel.
• Max. Suction Height: Capable of drawing water from depths up to 8 meters.
• Max. Liquid Temperature: Suitable for clear liquids up to +40°C to +60°C (varies by regional manufacturing standards).
• Inlet / Outlet Size: Universally threaded standard 1" x 1" connections.
• Electrical Safety: Equipped with standard Class F insulation and an IPX4 ingress protection rating. Single-phase configurations integrate an
