Brand: AQUASTRONG
Model: EKm80-1
Inlet / Outlet Size: 1" × 1"
Duty: Continuous Duty
Protection Features: Thermally Protected
Performance Data
Power: 0.75 kW / 1 HP
Flow Rate (Q): 5 – 50 L/min
Head Range (H): 8 – 56 m
Max Head (H_{\text{max}}): 62 m
Max Suction Lift: 8 m
Speed: 2900 r/min
Electrical Parameters
Voltage: 180 – 220 V~
Frequency: 50 Hz
Current (I_n): 5 A
Capacitor: 20 μF / 450 V
Insulation Class: Class F
Protection Class: IP44
