The image shows the technical specifications and wiring diagram for an AKIRA refrigerator, model MRF-438WD.
Here is a breakdown of the key specifications from the label:
Power & Energy
Voltage/Frequency: 220-240V ~ 50Hz
Total Input Power: 140W
Defrosting Power: 230W
Electricity Consumption: 0.885kWh/24h
Capacity & Dimensions
Net Capacity: 332L
Weight: 58kg
Freezing Capacity: 10kg/24h
Technical Details
Refrigerant: R600a (54g)
Foaming Agent: Cyclopentane (
)
Climate Class: SN/N/ST (Suitable for ambient temperatures from 10°C to 38°C)
